tilted by more than 2° during lifting. Since each   approach with modular trailers was the optimum
                             module had a different center of gravity and off-  solution to save time and cost, not all modules
                             axis orientation in both the X and Y directions,   were able to be installed by this method due to
                             hydraulic slings had to be strategically positioned   environmental obstacles hindering the movement
                             atop the lifting frame to provide adjustable support   of the loaded SPMTs at site. SPMT trailers could
                             to the Module’s four corners, ensuring balanced   not access installation areas of 23 stacked
                             lifting. Each hydraulic sling, or cylinder, was   modules, as the size of the modules exceeded the
                             carefully calibrated to accommodate the specific   limits of the final turns to the installation areas.
                             weight distribution and  dimensions of the   These modules had to be lifted from the top side
                             respective module. Through precise calculation of   by CJ ICM’s 1600 tons crawler crane to get over
                             the slings’ stroke setup, engineers ensured optimal   the obstacles and placed on their foundations.
                             balance between the modular lifting frame and the   These methodical approaches applied by CJ
                             load. Furthermore, to guarantee safety and   ICM’s engineers ensured the safe and efficient
                             compliance with tilt limits, rigorous testing   assembly and then installation of these heavy
                             procedures were implemented. Prior to lifting, all   modules, minimizing potential disruptions and
                             Modules underwent a comprehensive test lift to   streamlining the construction process. By
                             verify clearance from the ground within the   leveraging innovative techniques and equipment,
                             prescribed tilting parameters.            the  construction  teams  were  able  to  effectively
                             Another challenging  factor  was  installation   overcome the unique challenges posed by the
                             tolerance. These massive modules had to be   handling of these components in the unforgiving
                             stacked within a 30 mm tolerance. This was   conditions of the Iraqi desert.
                             mainly achieved thanks to the 90-degree axle
                             movement capability of SPMT trailers. Furthermore
                             tirfors were used from four corners for precise
                             alignment. Although this direct installation
