CASE HISTORY





                                Consequently, following               security, the SCAE scope of supply included redun-

                                the specific requests of the           dancy of communication with the DCS managed
                           “customer and accompanying                 via optical fi ber (always with two media converters
                                                                      to provide wired redundancy). This communication
                                 him in the technical choice of       has been tested during the FAT with the customer
                                 hardware, in compliance with         and will be tested during iFAT with DCS.
                                 the mandatory safety standards       Furthermore, SCAE has developed the software
                                 for the plant, SCAE has provided     and the HMI pages to permit the easy control of the
                                 the CPUs in redundant mode           packages, including the dynamic utilities of the he-
                                                                      ater matched with the blower, and has developed
                                                                      the preventive diagnostic, to permit the operator to
                            The High Availability solution (selected by SCAE)   execute the best maintenance on the mechanical
                            uses  redundant  components  with  Hot-Standby   parts.
                            performance. This means that both CPUs are   Thanks to SCAE software developers  and the
                            permanently running, operating in parallel, conti-  SCAE electrical designers’ experience, every elec-
                            nuously synchronizing each other and monitoring   trical part is constantly monitored and shown to the
                            the whole redundant system. If the primary CPU   supervisor and every process instrument has been
                            is stopped, powered off or crashed or if a remote   connected with a manageable HART Multiplexer
                            module line is disconnected, the other hot standby   (available to the DCS through optical fi ber with ano-
                            CPU takes over by adopting primary status.   ther media converter)
                            So SCAE, with this system, ensures continued re-
                            liable operation of the customer’s plant and appli-  Therefore, each critical point of the project has
                            cation.                                   been analyzed and handled by SCAE following the
                                                                      strict specifi cations of the fi nal plant and has been
                            In addition, in accordance with the required levels of   appreciated and accepted by the End-Customer.






                             Roberto Manzoni

                             Roberto Manzoni has graduated in Electrical Engineering at Politecnico of Milano; he has many years of
                             experience as Project Manager and as Electrical and Automation Project/Field Engineer, mainly in Com-
                             pressors, Dryers and Nitrogen production fi eld, for Oil & Gas; he has been working  with the most famous
                             multinational corporations for the realization of key projects around the world.
                             After having successfully conducted several SAT (Site Acceptance Tests) both Onshore and Offshore,
                             he has become SCAE Systems and Automation Department Manager; leading a team of coworkers, he
                             coordinates and manages the development and realization of Automation Projects for the following areas:
                             steel, cement, chemical and petrochemical industries, with particular attention to compliance with IEC
                             61508 and IEC 61511 standards, being certifi ed as TÜV RHEINLAND FS ENGINEER.





                  SCAE: Automazione per packages Oil&Gas



                  SCAE ha progettato e realizzato il Quadro di Comando e Controllo di un doppio dryer in modalità Master/Slave,
                  destinato al settore Oil&Gas, sviluppando anche il relativo software di gestione.
                  Le specifi che tecniche del cliente e gli standard di sicurezza del sistema hanno richiesto l’adozione di particolari solu-
                  zioni tecnico/costruttive quali, per esempio: carpenteria realizzata ad hoc in acciaio AISI316L, PLC in confi gurazione
                  ridondata, HMI di controllo locale, alimentazione indipendente e ridondata per gli avviamenti e i circuiti ausiliari di
                  ciascuno dei dryer, un sistema di automazione comprensivo di diagnostica preventiva.
                  Una volta eseguito con successo il FAT relativo al Quadro, SCAE ha affi ancato il cliente nelle procedure di FAT del
                  package e ha collaborato con l’End User nell’implementazione della comunicazione ridondante con il DCS deputato
                  al controllo centralizzato di detto package e delle altre apparecchiature ausiliarie dell’intero Impianto.
                  Nel corso del 2021 è previsto un iFAT per collaudare la sopracitata comunicazione ridondata con il DCS, e succes-
                  sivamente, appena conclusa la fase di installazione in cantiere, eseguire il SAT inviando i propri tecnici specializzati
                  per il commissioning defi nitivo.
