ration system with a steam turbine unit, critical to   combined a raft and numerous piles penetrating
            plant operations due to the limited power grid sup-  the ground. “Piles can be further optimized by wor-
            ply in the area and complex integration with the exi-  king together with the raft while maintaining the
            sting electrical network. In addition to these techni-  tower’s settlement within an acceptable range,” Ei
            cal challenges, the project presented logistical and   said.
            environmental difficulties, given its remote location.   During the construction phase, the contractor pro-
            A further challenge was meeting the client’s fast-  posed a sequential excavation process that divided
            tracked schedule. To overcome these complexities   the area into sub-zones—two for the MRT station,
            and accommodate the accelerated timeline amid   and one each for the tower and hotel—that would
            a team of engineers distributed globally across five   properly control the retaining wall deflections and
            offices, Hatch sought a sustainable technology so-  speed construction. However, this situation would
            lution, digitalizing all workflows and deliverables.   cause a significant impact on initial design pre-
            Upon completion, the DRC plant will be capable of   diction of soil movements. Hatch implemented a
            making all the sulfuric acid that the copper mines   collaborative digital strategy using Bentley’s open
            need while exceeding world standards for sulfur   applications, streamlining workflows and facilita-
            dioxide emissions, optimizing environmental su-  ting quality engineering processes that saved time
            stainability.                             and costs. The project team used STAAD to mo-
                                                      del and analyze the structural steel components,
            Open Applications in a                    and OpenPlant and OpenBuildings Designer to
                                                      create a digital twin model of the entire acid plant.
            Connected Data Environment                ProjectWise served as the collaborative platform to
            Streamline Workflows                      establish an open, connected data environment to
                                                      manage and share information across five globally
            Arup Singapore determined that the project would   dispersed engineering offices. “Bentley’s industrial
            require a detailed analysis of sub-soil conditions   plant products, and specifically ProjectWise, assi-
            performed using robust geotechnical solutions,   sted the teams in executing the project following
            which would provide the team with a solid founda-  the same work-sharing principles out of our offices
            tion to address the effects of excavation on the   in Canada, South Africa, India, Australia, and the
            older structures. However, the team had to do all   DRC,” commented Johan Palm, project manager
            of this while facing a tight deadline. To overcome   at Hatch.
            the challenge, Arup Singapore deployed Bentley’s   Bentley’s open applications provided flexibility
            gINT geotechnical and geoenvironmental softwa-  within the design environment, enabling a single 3D
            re to manage the data throughout its work. Using   model to be used for layout, analysis, design, and
            gINT, the project team examined the complex se-  fabrication. This flexibility also optimized coordina-
            diment and gave geotechnical engineers a better   tion throughout all stages of engineering and con-
            understanding of the soil properties of any given   struction, as well as presented opportunities to ca-
            area of the development. This capability also allo-  pitalize on digitalization to improve efficiencies. The
            wed engineers to accurately determine what spe-  interoperable digital technology allowed operations
            cial tests were needed for each section, as well   teams to interact in the model environment for ha-
            as helped team leaders easily communicate their   zard and operability study checks, improving ope-
            findings to project stakeholders. In just one week   rations reviews and enhancing operational safety.
            after completing ground-investigation works, the   Integrating Navigator facilitated digital communica-
            team was able to produce a full geotechnical inter-  tion with on-site personnel, commissioning teams,
            pretive report that assessed all soil properties and   and installation contractors through mobile devices
            ground risks.                             and tablets. Providing field teams with real-time di-
                                                      gital access to the accurate 3D model eliminated
                 The contractor Arup Singapore        time otherwise needed to deliver drawings on site,
                 deployed Bentley’s gINT              facilitated quality engineering, and enabled issues
                                                      to be resolved prior to construction and installation.
            “geotechnical and                         Overall, leveraging Bentley’s intelligent design and
                 geoenvironmental software            analysis applications within the connected data en-
                                                      vironment enabled Hatch to upstream quality pro-
                 to manage the data throughout        cesses, improve procurement and logistical strate-
                 its work                             gies, and minimize construction rework. The digital
                                                      solution allowed geographically dispersed teams to
                                                      jointly move the discrete paper isometric drawing
            The  gINT  study  revealed  that  the  ground  was  in   production process into continuous digital delivery
            reasonably good condition. However, the analysis   sets for site fabrication. This capability optimized
            also showed that the 290-meter tower would re-  coordination  between  global  delivery  teams  and
            quire a deep foundation to avoid disrupting the raft   site  fabrication  to  accommodate  the  aggressive
            foundation of the nearby MRT station. Ideally, the   schedule. By working in the connected data en-
            foundation would minimize ground disturbances   vironment with Bentley’s open applications, Hatch
            but remain flexible enough to allow for the tower’s   was able to accelerate project delivery, streamlining
            construction. Arup Singapore chose a design that   workflows to cut six weeks from the schedule and
