of acid washing can be determined only on the basis of   stainless steel (AISI 316) and after painted as per
                             field experience                          customer specifications with a detailed procedure.
                             So, this project concerns the automation of a package   All incoming power supplies (mains, auxiliary and UPS)
                             consisting of electrochlorination process designed and   are fully redundant and a redundant communication
                             managed by SCAE.                          with the DCS, managed via optical fiber (with two
                                                                       media  converters  to provide wired  redundancy), has
                                                                       been created to allow the complete supervision of the
                             The project: Hardware                     whole package.
                             and software design                       Consequently, following the specifications of the
                                                                       Customer and supporting them in the technical choice
                             The package consists of two electrolyzers, one   of hardware, SCAE has provided the CPUs in redundant
                             transformer rectifiers, one tank, several valves, and   mode.
                             electrical motors/components. Each item must be   The solution is a system that provides greater
                             used separately in manual or together in an automatic   availability. The system has greater availability because
                             cycle (Master/ Stand-by mode) in order to guarantee   it uses a redundant chassis pair which maintains
                             the best product based on field experience and these   process operation when some events, such as a fault
                             modes can be managed from the operator with an   on a  controller, occur  and  could  stop  process
                             easy and clear selection from the Unit Control Panel.   operations on non-redundant systems. The redundant
                             The  electrical  cabinet  that  controls  the  package  is   chassis pair includes two synchronized chassis with
                             completely designed and manufactured by SCAE to   identically specific components in each of them.
                             meet the end user’s requirements, from the enclosure   So SCAE, by this system, can guarantee continued
                             material, to each required certification, to the high   reliable operation of the customer’s plant and
                             degree of automation of critical points in the end user’s   application.
                             facility.                                 All the system has been tested during the FAT with the
                                                                       customer and will be tested during iFAT with DCS.
                                “The control and the precision of      In addition, SCAE has developed software and HMI
                                each part of the process were the      pages for easy management of the package, including
                              critical point and they have been the    dynamic utilities for all the electrical components, as
                                  starting points of the project       well as preventive diagnostics to allow operators to
                                                                       perform optimal maintenance on machine components.
                             SCAE’s electrical design team supported the customer   Thanks to the expertise of SCAE software developers
                             in selecting the various components at each stage and   and SCAE electrical designers, all electrical components
                             provided  all documentation  in  accordance  with the   are constantly monitored and shown on the HMI.
                             customer’s template.                      Then, SCAE has prepared a communication via optical
                             That said, the cabinet has been designed and built in   fiber protected with layer-3 switches to establish a
                                                                       tunnel for the remote control of the process in
                                                                       accordance with cyber-security norms requested by
                                                                       customer.


                                                                       SIL and IECEX certifications

                                                                       The icing on the cake of this project was the certification
                                                                       requested for SIL and the certification for IECEX zone
                                                                       of electrical cabinet provided by SCAE.

                                                                           “SCAE has developed the SIL
                                                                         ASSIGNMENT ANALYSIS - Analysis
                                                                          performed by SCAE FS Engineer
                                                                         (TÜV Rheinland certified. ID-No #
                                                                       18312/19)  - with all the calculations
                                                                          of the level reached and manual
                                                                          for safety dedicated only to the
                                                                              functional safety loops


                                                                       The analysis has demanded the selection of all the
                                                                       materials with attention for each detail in order to be in
