most importantly the fill media.
            •   The base support structure plays a crucial
                role in maintaining the stability and
                functionality of the filler. Structural
                requirements must be calculated in order to
                withstand the weight of the media fouled by
                microorganisms and any additional loads.
                The base structure  is not  only essential  for
                maintaining stability, but also for promoting
                efficient treatment and preventing blockages
                that  could  hinder  wastewater  flow  or air
                circulation.  Between  the  base  support
                structure and the pavement, the underdrain
                collects the treated wastewater from the filter
                and it creates a plenum (an empty space
                below  the  media)  that  facilitates oxygen
                transfer throughout the trickling filter. A larger
                and open underdrain area  promotes better
                air distribution.
            •   The containment structure could also be
                avoided if  self-standing plastic structured
                media is installed but some water spillage
                could be observed in this case. This is why
                light walls are generally sufficient to safely
                contain all the water flow. Thicker concrete
                walls  are  needed  when  motor  driver  rotary
                distributors are used, as in this project.
            •   The top distribution system provides for
                uniform distribution of wastewater over the
                media. Rotary distributors can be hydraulically
                or mechanically driven as in this project.
                Modern electric drives provide the ability to   BIOpack, are the heart of the system and
                control rotational speed, so that maintaining   they are specialized for different applications,
                a relatively slow rotational speed and high   like roughing applications  for handling high
                flushing intensity several benefits can  be   concentrations of pollutants, total carbon
                achieved such as biofilm thickness  control,   removal treatment like  in  this project,
                macro fauna control, and increased wetting   nitrification even at very low concentrations.
                efficiency.                              ENEXIO ITALY’s expertise is available to
            •   ENEXIO ITALY’s structured fillings, such as   clients for intelligent plant design and
                                                         operation,  selecting  the  most  appropriate
                                                         media for each application. Each channel
                                                         type and size is designed to work at best in
                                                         predetermined water hold up ranges, so that
                                                         the full surface of the structured media is
                                                         wetted by the percolating water but also that
                                                         the water quantity does not flood the
                                                         channels completely.
                                                      •   Plastic media, available as cross-flow or
                                                         vertical flutes, provide for better oxygen
                                                         transfer, and are lighter than rock, so media
                                                         can be deeper and the water and air flow is
                                                         much better. Vertical-flow media are used in
                                                         roughing and industrial applications: they are
                                                         the  least  likely  to  plug  and  grant  the  best
                                                         ventilation but redistribute wastewater only at
                                                         module interface and develop smaller specific
