increased risk of effluent violations. On the
                contrary low BOD loading rates are adopted
                for municipal wastewater treatment, which
                are  much  less  concentrated than industrial
                wastewaters, in order to meet low effluent
                concentrations. Anyway, a too low BOD
                loading rate may  indicate underutilization  of
                treatment capacity.
                Monitoring BOD loading rates helps operators
                assess  the  system’s  capacity  and
                performance.  It  guides  decisions related  to
                process adjustments like water distribution,
                recirculation, aeration, and allows evaluation
                of overall treatment efficiency.
                BOD loading rates vary based on influent
                characteristics, flow rates, and treatment
                plant design. Properly designed treatment
                systems balance BOD loading rates with   greater the flushing intensity required.
                available microbial activity according to the   Although many trickling filters have
                specific fill media characteristics.     hydraulically driven  distributors,  some
                In fact each channel type and size is suited   distributors are equipped with mechanical or
                for different organic loading ranges. Larger   other speed controls, as it is in this project.
                channels and vertical fluted channels are   As a result, speed-control distributors now
                needed as BOD loading increases.         often allow normal operational speeds
                                                         ranging from 4 to 10 minutes per revolution.
            •   The Hydraulic Loading Rate (HLR):        More importantly, many speed-control
                The hydraulic loading rate refers to the volume   distributors allow specifying a regular (daily or
                of wastewater applied to a treatment system   weekly) “flushing” speed that may slow the
                per unit of time per unit of horizontal area. It   distributor to more than 60 minutes per
                quantifies the flow rate of wastewater through   revolution.
                a specific treatment component and it is   Another design topic is determining the
                normally expressed in m3/m2/hour.        number of arms in the top distribution system:
                The HLR determines how much wastewater a   reducing it results in higher flow from each
                treatment system handles and it affects   arm, thus increasing the local flushing force
                the  contact time  between wastewater and   brought by the percolating water. This is
                treatment media (such as soil, filter beds, or   useful because the oldest (and less active)
                biological  reactors),  as  well  as  the  washing   portion of the biological film detaches from
                force applied to the fill media.         the media surface and is flushed to the
                From an operational point of view, high HLR   bottom of  the filter.  Excessive biofilm
                results  in  a  smaller  installation  footprint  and   thickness can impair oxygen transfer and limit
                provides strong flushing force to remove the   overall treatment efficiency. This flushing
                spoil film but may lead to inadequate    procedure avoids the clogging phenomenon,
                treatment due to insufficient contact time,   which is accumulation of excess biomass or
                resulting in poor effluent quality.      suspended solids on the filter media surface,
                On the contrary, low HLR provides longer   resulting  in  loss  of  treatment  and  other
                contact time for treatment and thus ensures   problems.
                higher treatment efficiency but it requires   The specific flushing rate depends on the
                larger installation footprint.           filter design, media type and organic loading.
                Treatment system designers consider HLR
                during system sizing and layout because   In conclusion, ENEXIO ITALY successfully
                while systems mut be able to accommodate   addressed  the  project  requirements  by
                fluctuations, balancing HLR with treatment   implementing the following strategies:
                efficiency is crucial.               1.  Careful Internal Stratigraphy Design:
                                                     •   ENEXIO ITALY meticulously designed the
            •   The flushing factor                      internal structure of the filter.
                Generally, the higher the organic loading, the   •   Higher thickness of the foil media were
