Table 2 - Results of case study 2

                                             High velocity system  2 stage medium velocity system
                                                                   4100 m3/h, filter
Air flow                                     7200 m3/h, filter     Cam-Flo XMGT, F7
Pre-filter stage                             bag filter G4         CamGT 4V-300; E12
Final filter stage                           bag filter M6         478 Pa
                                                                   -52%
Intial pressure drop over system 996 Pa

Reduction in air resistance

cartridge solution that has three times the amount of           losses due to high pressure loss through the inlet
media, compared to the original setup, for a significantly      system. Also, filtration efficiency for small particles are
higher dust holding capacity. The new deep filters did          significantly lower than those of a low- to medium
not only replace the existing cartridge filter, but also the    velocity system. In this case the operator was facing
F7 bag filter used in the pre-filter stage. To avoid            filter replacement every six months and the filtration
turbine fouling and engine degradation effects, the             efficiency did not reach over 70% on 4µm particles
filtration grade has been raised from F7 to F9                  which would equal M6 filter class according to
(EN779:2012) in the pre-filter stage, and from E10 to           EN779:2012.
E12 (EN1822:2009) in the final filter stage.
The CamGT E12 offers >99.5% MPPS efficiency –                        High velocity systems have the
meaning that it collects at least 99.5% of the particles         advantage of reduced size, weight and
most difficult to filter (approx. 0.1 - 0.2 µm in size).
Particles of all sizes, both bigger and smaller, are               lower initial cost. A disadvantage is
filtered more efficiently.                                       that there are performance losses due
                                                                 to high pressure loss through the inlet
Results of case study 1
                                                                   system. Also, filtration efficiency for
Not only is the turbine significantly better protected            small particles are significantly lower
with the CamGT 3V-600 E12, the initial dP has also               than those of a low- to medium velocity
been reduced to 200 Pa at 4400 m³/h, compared to
the 250 Pa with the original filter setup. After six                              system.
months of operation, pressure drop has remained low
and stable even during humid conditions and the                 A new air intake system was installed on one of two
engine performance has been improved significantly              neighboring compressor packages (16 MW aero
(table 1).                                                      derivative gas turbines). Past experience from
                                                                filtration offshore pointed towards a multiple stage
Case Study 2                                                    filtration system but the weight and space
                                                                restrictions limited the options to a 2 stage system.
High velocity system replaced by                                The harsh environment offshore called for a solution
medium velocity deep filter solution                            with high resistance to humidity and salt. If salt is
                                                                ingested in the turbine the operator face the risk of
One of the world’s leading oil & gas companies had              irreversible damage to the turbine and extremely
severe problems with the operation of their gas                 costly downtime for engine overhaul. The filtration
turbines offshore, with frequent filter replacement             efficiency must, according to experience be above
intervals and engine degradation. Many of the turbines          99%, so the filtration grade was set to E12
also suffered from corrosion damages due to poor                (EN779:2012).
filtration efficiency.                                          The new air intake system had a first pre filtration
The fleet of gas turbines for mechanical drive, 16 - 30         stage, a bag filter for applications in high humidity
MW, were all equipped with high velocity systems. A             filtration class F7. The final stage was equipped with a
high velocity system is normally a one stage filtration         CamGT 3V-600 deep filter with more than 50 m²
system with a droplet separator before and after the            effective filtration media.
filtration stage. High velocity systems have the                This situation with two air intakes in identical
advantage of reduced size, weight and lower initial             environments provided an excellent opportunity to
cost. A disadvantage is that there are performance              demonstrate the benefits of employing a high efficiency
                                                                deep filter solution (table 2).
