•   A consequence of the clamping contact is that the
                stator is a wear part, to be exchanged at regular
                intervals that depend entirely on the application
                and are hard to predict. Non-stop operation over
                three years as required by API 676 (para 6.1) is not
                something a PCP can guarantee.

            4. There is the eccentric kinematic of the rotor
            and its impact on vibration:
            •   For a given capacity, vibration levels of a PCP are
                necessarily higher than other API 676 pump types
                based on concentric motion. A standard PCP may
                exceed the limit of 3.8 mm/s (para 6.11).  cross-reference other API standards or US
            •   This low frequency vibration is inherent in the   manufacturing standards.
                design and not a sign of trouble, thus vibration
                monitoring makes little sense.       6. Gearbox and bearings
            •   Vibration is a critical issue and limiting factor only   •   API 676 references AGMA and ABMA standards
                for vertical semi-submersed PC pumps, where the   and requires gearboxes > 18 kW (25  HP) to
                shaft can become several meters long.    conform with AGMA 6010, or even API 677.
                                                     •   API 677 gears are generally not available for the
            5. PCPs typically operate at slow speed 100 -   typical power ratings and drive configuration of
            300 rpm, about 10-20% of a centrifugal pump.   PCP. Please refrain from specifying API 677; pump
            Thus:                                        vendors could not comply even if they wanted to.
            •   There  is  no  motive  for precise alignment  or   •   Outside the Americas the AGMA and ABMA
                balancing. PCP baseplates are typically not   standards are not used. European gear
                designed with precision machined pads and   manufacturers will design and calculate according
                jacking screws that facilitate alignment.  to DIN 3990 or ISO 6336. American and European
            •   Shaft bearings are grease lubricated and typically   gear standards are not compatible because they
                sealed / lubricated for life. Elaborate oil lubrication   are based on different physical models and basic
                systems with associated monitoring and cooling   assumptions. It is also not possible for the vendor
                function are not needed but nevertheless specified   to demonstrate that a gearbox designed to DIN/
                by API 676 / API 614 and present in the mind of   ISO is ‘equal or better’ to an AGMA design, which
                project engineers familiar with other pump types.  is a frequent requirement of project engineers
            •   It is common practice for PC pump design to omit   trying to circumvent the issue. Sometimes this
                dedicated shaft bearings altogether and use the   leads to a hot debate of almost religious
                gearbox  bearings  to  support  the  shaft  –  this  is   dimensions without practical result. Comparative
                called “block pump” and it can omit also the   papers by gear specialists can be found on the
                coupling.                                web. However, it is absolutely safe to assume that
            •   Shaft seals do not generate much heat by friction,   a gearbox following European standards will
                therefore, seal cooling is rarely needed and   perform just as well.
                standard seal plans offered by PCP vendors may
                minimize or omit the cooler, as a deviation from   7. IEC/IEEE
                API 682.                             API 676 requires motors to follow IEEE 841.
                                                     •   However, most international projects outside the
            Finally, there are those exceptions that are related to   Americas prefer IEC motor standard. IEEE 841
            sourcing and US standards. API standards usually   motors are only produced in the Americas; import
                                                         by European pump vendors raises the price and
                                                         lead time.

                                                     8. Welding
                                                     •   API 676 references ASME BPVC IX for welding of
                                                         pressurized  parts  and  AWS  D1.1  for  structural
                                                         welding.
                                                     •   While ASME IX is customary in Oil&Gas
                                                         applications, most European workshops are
                                                         basing their fabrication on ISO standards which
