Customized Contract
and Technology Applied
for the Zubair Oil Field in Iraq

A success story witnessing Nidec ASI’s capacity to provide
solutions which can meet the challenging and complex
requirements of the oil & gas market

Gianfranco Zocco
Nidec ASI

                                                                                              in 1949, this is a principal field both in the Middle
                                                                                              East and worldwide. Production is expected to
                                                                                              gradually increase during the coming 20-year
                                                                                              long exploitation term from the current amount of
                                                                                              0.2 million barrels-per-day to 1.0 million by 2035,
                                                                                              Termomeccanica Pompe’s customer was Eni Iraq,
                                                                                              a member of the consortium (Eni, Oxy, Kogas,
                                                                                              Missan Oil) redeveloping the field and building the
                                                                                              new plant, under the strict supervision of the South
                                                                                              Oil Company, part of the Iraqi Ministry of Oil and the
                                                                                              end user’s consultant.

Fig.1 – Zubair Field location  Over the past decades, the                                       A consolidated technology in this field
(from Wikipedia and Google                          exploitation of giant oil fields has       entails induction motors fed by voltage-
Earth)                                              seen the development of electric           source inverters to drive machines such
                                                    drives with increasingly high power       as pumps, compressors etc. at a variable
                                                    ratings, high efficiency, operational       speed, increasingly rated 10÷20 MW
                                                    flexibility and high reliability able to   and specifically designed for this kind of
                               meet the harshest environmental conditions.
                               A consolidated technology in this field entails                       application and environment
                               induction motors fed by voltage-source inverters to
                               drive machines such as pumps, compressors etc.                 The pumping units will be installed in three different
                               at a variable speed, increasingly rated 10÷20 MW               sites (Hammar, Mishrif and Rafidya), almost
                               and specifically designed for this kind of application         inaccessible areas, where the severest and harshest
                               and environment.                                               environmental conditions entail the application of
                               This paper presents a success story witnessing                 stringent design regulations in order to ensure the
                               Nidec ASI’s capacity to provide solutions which can            total reliability of the machinery. For such a high-
                               meet the challenging and complex requirements of               performance task, Nidec ASI developed a specific,
                               the oil & gas market.                                          edge-technology drive concept, and supplied the
                               In 2013 Termomeccanica Pompe was awarded                       Power Drive System (PDS) to Termomeccanica
                               the contract for the supply of 12 pumping units                Pompe for their water injection pumps.
                               for the redevelopment of the Zubair (Az Zubayr)                •	 Nidec ASI’s scope of supply consisted of:
                               Oil Field in Southern Iraq (figure 1). Discovered              •	 total electric power of 110,4 MW;
                                                                                              •	 12 PDS for water injection pump trains;
                                                                                              •	 full-load system, tested at the Nidec ASI

                                                                                                    facilities in Monfalcone (Italy) and pumping unit

                                                                                              Impiantistica Italiana - Maggio-Giugno 2015 59
