The first actions are related to those that each of us   of inter fraction, such as RDF.  The reactor is able to
                             can implement. The reduction of the amount of waste   melt the ash fraction of the waste to produce a vitrified
                             produced relies on everyday life activities.  Each of us   granulate applicable as a raw material for ceramic and
                             can devote his efforts to reducing the amount of waste   concrete production as substitution of minerals.
                             individually generated. In addition, he can apply the   Meanwhile, the reactor is able to convert the
                             concept reuse, asking himself “should this material   combustible fraction of the waste into a valuable gas,
                             really to be thrown away?”. And if you have to resort to   called  syngas,  composed  mainly  of hydrogen and
                             throwing it out, differentiating, if possible. This is where   carbon monoxide.
                             the citizen’s task ends and industry, technology and   The waste to chemical process is composed of five
                             innovation take over. The differentiated product classes   main sections, as seen in Figure 2.
                                          can therefore be mechanically
       “Waste to chemicals represents     recycled. But not all the differentiated   1. High temperature gasification. As mentioned above,
       a valid alternative to fractions of   fractions can actually be recycled. A   this is the core of the overall process, since the
       waste that are not mechanically    fraction of waste always exists,   combustible  fraction  of  the  waste  is  converted  into
         recyclable, which can then be    larger or smaller depending on the   syngas, while the inert fraction of the waste is melted
       chemically converted to produce,    type of material and collection. This   –  thanks  to the high  temperature reached – and
              for example, fuels          is where innovation comes in. Waste   collected as a vitrified granulate material.

                                          to chemical represents this: a valid   The reactor, according to the temperature profile, can
                             alternative to fractions of waste that are not mechanically   be schematized as divided in three zones, as seen in
                             recyclable, which can then be chemically converted to   Figure 3:
                             produce, for example, fuels.              a.   Melting zone. Where pure oxygen is fed as a
                             The typical feedstock of a Waste to chemical process   combustion and gasification agent. The
                             are Refuse Derived Fuel (RDF), which is the dry fraction   exothermal nature of the oxidation reactions
                             of unsorted municipal solid waste and the non-  allows the temperature to reach above 1600°,
                             recyclable plastic; any other waste fraction that is   thus making it possible to melt the inert fraction
                             impossible to recycle in an alternative way can be sent   specifically contained in the waste.
                             through  the  process.  An  example  of  the  average   b.  Partial oxidation zone. A balance of gasification
                             compositions, by weight fraction, of the two mentioned   reactions implies the further conversion of the
                             fractions is reported in the table below.    combustible fraction, but also a reduction of the
                             It is important to notice the content of carbon and   average working temperature (700°C).
                             hydrogen. These elements are usually taken from fossil   c.   Stabilization zone. Called stabilization since the
                             resources. The rationale in a Waste the chemical   gas produced is slowed down when it reaches
                             process, is instead to produce fuel or chemicals by   the  enlarged  reactor  section,  and  further
                             converting the carbon and hydrogen contained in the   converted by the introduction of more oxygen
                             waste which would otherwise be disposed of or at best   which allows the temperature to elevate up to
                             recovered only in terms of energy.           1100°. In this way a very valuable syngas is
                             The conversion of carbon and hydrogen is performed   produced: free of TARS or dioxins.
                             by a high temperature melting gasifier which is the core   2. Syngas cleaning and storage. As the syngas is
                             of the process. The particularity of this technology is   coming out from the gasification reactor, it is abruptly
                             that it is able to convert feedstock with a high content   cooled from 1100°C to 90°C in order to freeze the
                                                                       composition and avoid the formation of toxic
                        RDF             Non-recyclable plastics        compounds. The cold syngas is sent to two scrubbers
                                                                       and an electrostatic filter to perform a preliminary
           C            40-55%          47-61%                         cleaning. The cleaned syngas is then sent to a gas
           H            5-8%            5-7%                           holder in order to control the potential fluctuation of
                                                                       flowrate.
           O            20-28%          14-20%
                                                                       3. Syngas compression and purification. Syngas from
           Cl           0.5-3%          0.8-1.5%                       the gas holder is compressed and purified through
           N            0.5-1.5%        0.2-0.5%                       several steps, including adsorption beds, hydrolysis,

           S            0.1-1%          0.02-0.3%                      and sulfur removal, in order to achieve a thoroughly
                                                                       polished syngas which cannot contaminate the
           Moisture     10-20%          5-9%                           catalysts of the following step.
           Ash          5-20%           7-20%                          4. Syngas conditioning. Both methanol and ethanol
                                                                       would  require  a higher  H2/CO ratio than the  one
          Table 1. Average elemental compositions of Refuse Derived Fuel and Non-  coming directly from gasification, which is about 1.
          recyclable plastics.                                         Thus, according to the final product desired, the
