Notiziario












                                                                        stand the extreme temperature differentials between day and
                                                                        night in the Oman desert, which can cause potentially dama-
                                                                        ging condensation.

                                                                        “We  have exceptional  experience  of  developing  complete
                                                                        drive solutions for oil & gas applications – both upstream and
                                                                        downstream – and our involvement in such a major project
                                                                        as the PDO SaihRawl Field is a fine example of our commit-
                                                                        ment to help the oil & gas industry operate more efficiently
                                                                        and reliably,” comments Colin Cox, Managing Director, WEG
                                                                        Middle East.

                                                                        WEG offers one of the broadest ranges of energy-efficient
                                                                        explosion-proof motors currently available with rated power
                                                                        from 0.12 kW to 5.6 MW and frame sizes from IEC 71 to
                                                                        800. For example, the W22Xd IE4 Super Premium motor- the
                                                                        most energy efficient flameproof motor available on the mar-
                                                                        ket - combines explosion protection with IE4 efficiency levels
                                                                        and offers a long service life and low maintenance costs, hel-
                                                                        ping businesses in the process industry increase productivity,
                                                                        improve reliability and cut costs by up to 40% compared to
                            harmonic filter to reduce problems relating to mains borne   conventional models.
                            corruption of the power supply, while an output filter will be
                            used to protect the drive.                  WEG’s drives minimise voltage surges by carefully regulating
                                                                        the time between the pulses of their IGBTs (integrated gate
                            WEG’svariable speed drive systems have been tested at its   bipolar transistors). This decreases the possible surge ma-
                            manufacturing facility in Brazil in the presence of inspectors   gnitude and also allows longer cable runs without detrimen-
                            from PDO and Larsen & Toubro to simulate the harsh envi-  tally affecting motor insulation.
                            ronmental and operating conditions that may occur in the
                            field. WEG is also conducting performance tests of the mo-  Its patented flux optimising technology reduces input current
                            tors at the fan manufacturer’s plant in Korea and has orga-  by up to 50% of the motor rated speed, which decreases
                            nised training sessions for PDO staff in the Brazilian factory.   motor temperature rise by as much as 11%. Insulation life,
                                                                        and therefore motor life is extended because it is doubled for
                            Thanks to its vertical manufacturing process, WEG has also   every 10° C decrease in its operating temperature. Alterna-
                            been able to supply Larsen & Toubro with all of the overloads,   tively, output torque can be increased by 50% of the motor
                            switchgear, relays and push buttons used within the drive   rated speed to suit more demanding applications.
                            cabinets, thus ensuring component compatibility and trouble
                            free system building and commissioning as well as efficient   “Thanks to this high performance drive and motor architec-
                            ordering and delivery. Other elements in the cabinet inclu-  ture, WEG products are the perfect solution for the most ar-
                            de a control power transformer and auxiliary contactors and   duous industrial applications, such as those that are likely to
                            circuit breakers. Additionally, a door mounted control panel   be foundin Oman’s PDO SaihRawl Field Depletion Project,”
                            incorporates a backlit LCD keypad, while a redundant serial   concludes Colin. “WEG can provide the ideal explosion-proof
                            link (2 channels Modbus-RTU over RS485) provides com-  motor for virtually every application, even with extreme ope-
                            munication to the wider control system. Finally, the control   rating conditions such as ambient temperatures from -55°C
                            cabinets include space heaters, which are essential to with   to +80°C and altitudes up to 5,000 m”.























                                                                                   Impiantistica Italiana - Maggio-Giugno 2017  123
