RENEWABLES






       Detailed block flow diagrams of the Bio-  lene that have not been fully removed or   now ready for small scale and multipurpo-
       SNG production starting from biomass   decomposed in the previous steps should   se commercial applications.
       gasification, biogas upgrading, and power   also be reduced down to acceptable le-  Stein and Ray (2016) provided a techni-
       to gas including the explained sections are   vels for the downstream catalytic metha-  cal and economical assessment of an
       reported in Figure 3 a, b, and c, respec-  nation (typically less than 5 ppm vol).  industrial scale biomass gasification and
       tively.                                                              SNG plant, using woody materials as
       The first pathway to produce a clean gas                             feedstock, demonstrating that the inte-
       that can be converted into Bio-SNG is the                            gration between biomass gasification and
       biomass gasification.  SNG can be pro- VESTA technology              VESTA catalytic methanation is feasible for
       duced from biomass by using different   integration for Bio-SNG      both small scale and large scale bio based
       plant configurations, which depend on                                units. The plant configuration chosen was
       the selected gasification technology with  production                selected by Stein and Ray (2016) accor-
       an impact on the downstream syngas   Today, more than ever, the bio based   ding to the following basis. The main input
       conditioning and cleaning steps (Dome-  sector starting is seeing the interest and   data are relevant to the woody material
       nichini et al., 2016). Gasification techno-  investment of the main European Com-  feedstock and the outlet thermal power
       logies can be oxygen-blown or air-blown   munity states’ members. Considering   of produced SNG of approximately 200
       and have applications  for various  wood   these current incentives, a number of stu-  MWh, which  correspond to  a product
                                                                                               3
       and waste based fuels. Feedstock prepa-  dies proved that the biomass gasification   flowrate  of  21,000 Nm /h.  The adopted
       ration and gasification  (e.g., with oxygen   followed by a suitable polishing step and   biomass  gasification  technology  was  the
       coming from an Air Separation Unit), tar   the clean gas methanation is a viable and   Continuously Fluidized Bed, which is pres-
       removal, gas cooling and clean-up, and   economically attractive solution to produ-  surized and oxygen blown. The final clean-
       clean syngas  methanation  are the main   ce Bio-SNG. The aim of this Section is to   up is based on catalytic reforming for tar
       sections involved in the general process   prove that biogas upgrading is as feasible   removal and physical solvent washing of
       scheme proposed in Figure 3 a. Exam-  and efficient as the Power to Gas appli-  H S, followed by VESTA clean syngas me-
                                                                              2
       ples of biomass gasification are reported   cation and biomass gasification to gene-  thanation and chemical solvent washing
       also in Mancuso (2015), Domenichini et al.   rate  a  clean  syngas  and  a  subsequent   for the CO  removal.
                                                                                    2
       (2016), and Stein and Ray (2016).  Bio-SNG that can be integrated into the   Considering a middle term forecast for the
                                         existing natural gas networks for transpor-  natural gas price of 8-10 $/MMBtu the
           Biogas upgrading through      tation and heating purposes.       biomass gasification plant can be econo-
           the VESTA process for         Main technologies are available and matu-  mically attractive with an incentive in line
                                         re for commercial application for the three
                                                                            with what  currently applies  in Northern
      “SNG production is proved          renewable process schemes in Figures 3   Europe, or alternatively considering a mo-
           to be technically feasible    a, b, and c.                       netization for the low level heat integration
                                         Starting  from  the  available  data  in  litera-  (e.g., district heating). Biogas upgrading
                                         ture and from previous studies, a techni-  and  Power  to  Gas  alternatives  will  allow
       Biogas upgrading is the second pathway   cal assessment of the VESTA integration   the widest use of Bio-SNG to provide an
       to  produce  Bio-SNG  that  deals  with  the   with biogas upgrading for the Bio-SNG   alternative for transport, industrial, and
       integrated SNG production from biogas   production was performed and the main   domestic demands in all the green eco-
       and renewable hydrogen (i.e. from elec-  results collected.          nomies.
       trolytic cells). Likewise the first pathway,
       the  syngas  conditioning  and  cleaning
       steps can vary depending upon feed gas  Previous studies             A case study:
       composition. Figure 3b shows the block   The paper of Chandel and Williams (2009)   Biogas upgrading with
       flow diagram  of biogas upgrading  and   identified the conditions under which SNG
       SNG production from purified biogas and   production is economically viable by focu- VESTA technology
       renewable  hydrogen,  which  includes  the   sing on the process scheme of the coal-  The case study presented in this paper
       following sections: biogas clean-up (deep   to-SNG. The three pathways proposed   addresses the biogas upgrading integra-
       desulphurisation, dehalogenation, and   in this  paper have  advantages because   ted with Wood’s VESTA technology. The
       compression), clean syngas methanation,   biomass is carbon-neutral, and above all,   process scheme that is the core of this
       CO  removal system, and SNG drying.  CO  capture would generate null carbon   case study is provided in  Figure 3b.
         2
                                            2
       Power to gas applications typically pro-  emissions.  Likewise  any  other  methana-  The syngas coming to the methanation
       duce CO  rich gases that can be adapt   tion process, inlet syngas must be purified   section  has  no  specific  limitation  of  un-
              2
       for the Bio-SNG production.  Figure 3c   before  entering  the  methanation  section   desirable compounds, since adequate
       shows the block flow diagram of this pro-  and the purification step is defined accor-  treatment can be included in the SNG
       cess scheme , which deals with the CO    ding the impurities to be removed in the   unit scope. The selected plant configura-
                                       2
       rich gas conversion to Green-SNG by   specific application. For instance, one of   tion deals with 3 MWh of biogas and 550
       using renewable hydrogen and the subse-  the issues associated with biomass gasifi-  Nm /h of hydrogen as feedstocks and an
                                                                               3
       quent drying section.             cation is tar formation. Tar can be removed   outlet thermal power of produced SNG of
       The purification of synthesis gas essen-  through specific processes downstream   4.4 MWh. These additional basis relevant
       tially consists of acid gas removal (H S,   of the gasifier, such as water scrubbing, oil   to the integrated scheme have been ap-
                                     2
       COS, HCN, NH , etc.) which can be obtai-  scrubbing, thermal cracking, catalytic cra-  plied for the case study:
                   3
       ned through either physical or chemical   cking (Domenichini et al., 2012). All the re-  •   Renewable hydrogen generation in-
       absorption. Additionally, residual compo-  quired technologies for the polishing steps   volves electrolyzes
       nents like benzene, toluene or naphtha-  and the subsequent methanation are by   •   Final clean-up is mainly based on ei-
