RENEWABLES






                                                                            sign and optimize the integration system
                                                                            in order to satisfy the client’s needs. The
                                                                            final number of methanators is optimized
                                                                            balancing CAPEX and OPEX and conside-
                                                                            ring the provided syngas and the required
                                                                            SNG quality. As previously explained, re-
                                                                            action runaway conditions are the major
                                                                            concern in the methanation process. Sin-
                                                                            ce in VESTA process this risk is avoided
                                                                            thanks to the presence of CO  that acts as
                                                                                                   2
                                                                            a thermal flywheel and moderates tempe-
                                                                            ratures, the CO  is chosen to be removed
                                                                                        2
                                                                            downstream  of  the  methanation  section
                                                                            rather than upstream. This strategy eli-
       Figure 1 – The concept of available methanation processes. The main sections are in order: gasification,   minates the need for reaction gas recycle
       sour gas shift, acid gas removal, and methanation block. Two main features are highlighted: the   and its associated compressor and costs
       need of recycle compressor to handle the exothermic reactions and the complex adjustment and   in terms of consumptions and installation.
       continuous control of the feed gas composition to achieve on-spec SNG.  In addition, this choice permits to use a
                                                                            simple CO  removal system to produce
                                                                                     2
                                                                            high purity CO  (e.g., amine, hot carbona-
                                                                                       2
       (Ruggeri and Romano, 2014). In order to   such risk is avoided due to the presence   tes) because at that point the gas does not
       moderate the exothermic methanation re-  of CO  and water, which act as temperatu-  contain any other contaminant and easily
                                              2
       action temperature and avoid reaction ru-  re dampers. In contrast to other available   produce high purity CO . Since sulphur
                                                                                                2
       naway, several techniques can be emplo-  technologies, CO  removal in the VESTA   compounds such as H S, mercaptans,
                                                       2
                                                                                                2
       yed, such as the recycling of products, the   process is performed downstream of the   COS, thiophenes, etc., are poisons for the
       dilution of process gas with inert or steam,   methanation reactors rather than before   downstream catalyst, the syngas can be
       or the installation of isothermal reactors.  the methanation section, and there is no   conditioned upstream by means of several
       The most common choice of standard   need of product recycle compressors. For   techniques, e.g. AGR, catalytic removal.
       technologies (Figure 1) to moderate the   the sake of clarity, Figure 2 shows sche-
       heat of reaction is the recycle of reacted   matically the concept of the once-through   VESTA technology in
       gas which has, as the main drawback,   VESTA process.
       the need for a recycle compressor which   In the VESTA SNG process, sulphur-free   Wood portfolio has great
       complicates the scheme of the plant and   syngas (e.g., coming from an acid gas “flexibility in terms
       represents a significant part of the asso-  removal (AGR) unit) is routed to a sweet   of gas quality and adapts
       ciated investment cost and of the overall   shift reactor in which the high temperature
       power consumption.                water-gas shift reaction (3) happens:   to renewable resources
       For the sake of clarity, Figure 1 shows a   CO+H O↔ CO + H 2   (3)
                                              2
                                                     2
       typical conceptual scheme of the standard                            At the beginning, Foster Wheeler  suc-
       methanation process based on recycle of   The stream leaving the shift reactor is sent   cessfully developed a plant design with
       converted  gases. Moreover, in order to   to the methanation reactors where the re-  a very simple process scheme that le-
       obtain the desired SNG quality, a complex   action (2) takes place:  ads to excellent performance. The plant
       adjustment  of  the  syngas  composition   CO+3H ↔ CH + H O                 (2)  performances were modelled with com-
                                                     4
                                                        2
                                               2
       has to be performed across the Sour Shift                            mercially available process simulators,
       block, as well as a compositional control   This highly exothermic reaction is carried   with the reactor performances regres-
       on a continuous basis in order to achie-  out across a series of reactors with inter-  sed on the basis of reserved laboratory
       ve the SNG of the correct quality without   stage heat recovery. Wood is able to de-  data measured by Clariant. Then, Foster
       downstream functionality issues.
       VESTA process
       In this field, Foster Wheeler developed a
       simple methanation process, called VE-
       STA in 2006, using catalyst provided by
       Clariant, formerly Foster Wheeler’s and
       now Wood’s partner in SNG technology.
       The technology is based only on well-pro-
       ven equipment, such as fixed bed reactors
       and shell and tubes heat exchangers, and
       the catalyst has already been extensively
       tested by Clariant (Ruggeri and Romano,
       2014).
       In conventional  SNG processes,  the risk   Figure 2 – The concept of VESTA process. The main sections are in order: gasification, sulphur
       of runaway of the methanation reaction   removal, methanation block, and CO  removal. CO  and water in syngas control the exothermic heat
                                                                  2
       is very high, while in the VESTA process   of reaction with no need of product recycle.  2
