1.3.1 C1) Complete unit test in closed                   estimated in the operating conditions of the project.
                   loop
                                                                            We call:
                   It is called Type 1 in accordance with ASME PTC
                   10, Chapter 3.2 - Types of Tests.                        •	  rPHQassstpppecccdttthhhpeeeossinppctee)a;cclciiffuiieeladdtehfldoewapd(oa(watttehtrheedrareatmetedadnpdpooini(nat)tt;); the
                   It is performed using test gas, available at factory.    •
                                                                            •
                   Test gas
                   It is mainly methane plus some additives, dosed in       •	  Qtest  the  flow rate in the test;
                   such a way to reproduce the same density of the          •	  Htest  the  head measured in the test;
                   process gas. Slight deviations on the gas density        •	  Ptest  the  power measured in the test.
                   are allowed, within specified limits.
                   The test is performed at full pressure, full-speed,      The relationship for the power is the following:
                   full load, full density. The train operating parameters
                   are recorded, both at guarantee point, both at           Pspc = Ptest (Qspc Hspc) / (Qtest Htest)
                   other operating points.
                   The Complete unit test Type 1 appears to be the          WeqhuearletoPsoprc,lothweermtheaansutrheed   power value,    must  be
                   most complete test.                                                                                  value resulting  from  the
                   At the end of the test there is a technical meeting
                   between the Manufacturer and the Customer’s              calculation.  tIhf ethpeoPwsepcr  is lower than  the predicted
                   representative to discuss the acceptability of the       one, since                        consumption    is lower than
                   recorded results.
                   If the test is evaluated acceptable, the train is then   expected, the performance is greater.
                   removed, the various components separately
                   packed and prepared for shipment to the field.           1.3.3 C3) No load Complete unit test

                   1.3.2 C2) Complete unit test in closed                   The test is carried out on the complete train, with
                   loop similarity                                          no load. No test gas is used. Mainly the vibration
                                                                            levels and functionality of the auxiliaries are tested.
                   It’s called Type 2 according to ASME PTC 10,
                   Chapter 3.2 - Types of Tests.                            Test bed (figure 3)
                   Test gas has lower density (lean gas). This allows       For the execution of the Performance Test the
                   lower power consumption and lower heat to                Manufacturer is equipped with a “closed loop”
                   dissipate in the cooler.                                 (figure 4), which collects the test gas from the
                   The test is performed at lower speeds, pressures,        compressor outlet and send it back to the inlet,
                   flow rates, power, in terms of similarity. Appropriate   after cooling and depressurization.
                   calculations allow to go back to the values              The system is mainly composed of:
                                                                            •	 manifold;
                                                                            •	 pressure reducer valve;
                                                                            •	 heat exchanger;
                                                                            •	 piping;
                                                                            instrumentation.

Fig. 3 - Test bed
