           Ringraziamenti
           Gli autori ringraziano Trans Adriatic Pipeline AG.

           Bibliografia
           1.   Hill K.O., Fujii Y., Johnson D. C., Kawasaki B. S., “Photosensitivity in
              optical fiber waveguides: application to reflection filter fabrication”, Ap-
              plied Physics Letters, 1978, vol. 32, no. 10, pp. 647–649
           2.   Meltz G., Morey W. W., Glenn W. H., “Formation of Bragg gratings
              in optical fibers by a transverse holographic method,” Optics Letters,
              1989, vol. 14, no. 15, pp. 823–825.
           3.   Mendez A., Morse T.F., Mendez F., “Applications of embedded optical
              fiber sensors in reinforced concrete buildings and structures”, Proc.
              SPIE 1170, Fiber Optic Smart Structures and Skins II, Boston,  United
              States, 1990, pp. 60–69.
           4.   Inaudi D., Posenato D., Glisic B., Miller J., Graver T., “Combined static
              and dynamic monitoring of civil structures with long-gauge fiber optic
              sensors”, IMAC-XXIII a Conference on Structural Dynamics, Orlando,
              USA, 2005
           5.   Lai J., Qiu J., Fan H., Zhang Q., Hu Z., Wang J., Chen J., “Fiber Bragg
              Grating Sensors-Based In Situ Monitoring and Safety Assessment of
              Loess Tunnel”, Journal of Sensors, 2016, vol. 2016, 10 pages
           6.   Lin Y., Chen J., Chern J., Chang K., Lai, J “Real-time monitoring of
              local scour by using fiber Bragg grating sensors”, Smart Materials and
              Structures, 2005, Vol. 14, no.4
           7.   Peng H., Chen B., Dong P., Chen S., Liao Y., Guo Q., “Application of
              FBG Sensing Technology to Internal Deformation Monitoring of Lan-
              dslide”, Advances in Civil Engineering, 2020, vol. 2020, p. 10
           8.   Brower D.V., Prescott N., “Real Time Subsea Monitoring And Control
              Smart Field Solutions”, Subsea Rio 2004 Conference, 2004

    Monitoring measurement system

    of the TAP landing microtunnel
    based on Bragg technology



    This article describes the measurement system and methodology used for mo-
    nitoring the structural integrity of the microtunnel (MT) that hosts the final section
    of the Trans Adriatic Pipeline (TAP) on the Italian coast. TAP allows the transport
    of natural gas from the Caspian Sea to South-Eastern and Western Europe. The
    offshore part of the work, approximately 105 km long, plunges into the Adriatic
    in Albania and lands in Italy on the coast of the Puglia region, in the municipality
    of Melendugno (LE). The landing in Italy of the TAP gas pipeline is achieved
    through microtunnelling technology, which allows the installation of the pipeline,
    without the need to provide “open air” excavations, minimizing the impact with
    the coastal territory. The MT, with a length of 1,540 m, an internal diameter of
    2,400 mm and an external diameter of 3,000 mm, provided for the laying of the   Oil & Gas   Food & Pharma
    pipeline by means of a pushing process: the excavation was carried out by me-  Chemical   General Industry
    ans of a guided, remote-controlled milling shield, called Tunnel Boring Machine   Power   & Water
    (TBM), which was pushed into the ground, followed by watertight segments in
    prestressed concrete, subsequently joined to form a continuous tunnel, inside
    which the gas pipeline was launched. The free gap between the pipeline and the
    gas pipeline is flooded with sea water. In compliance with the maintenance plans
    and the requirements of the Fire Brigade, the MT must be subjected to periodic
    inspection to verify the structural integrity and the absence of obstructions in the
    vent pipes. For this purpose, an innovative methodology was proposed, based
    on monitoring the deformation measurements, obtained through the installation
    of strain gauge stations along the MT of the TAP landing stage. These sensors
    are written directly inside the fiber sensing cables of which the axial extension is
    calculated, based on FBG (Fiber Bragg Grating) optical technology. The senso-
    rized cables are suitably constrained on the internal surface of the MT, between
    specific fixed points integral with the concrete segments. This article deals with   AUDCO ITALIANA srl
    the system architecture, the selection of materials, the installation procedure and   Via Carlo dell’Acqua, 1- 20027 Rescaldina (MI) - Italy
    measurement acquisition in detail.                               Tel. +39 0331 1561323 - Fax +39 0331 1561327 - info@audco.it - www.audco.it  59 59
